3004 aluminum foil
3004 aluminum foil product
3004 alloy foil is a common product in the aluminum-magnesium-manganese alloy series. Because 3004 aluminum foil contains manganese and magnesium alloy elements, it has excellent anti-rust properties and is also called anti-rust aluminum alloy. Reference:
3004 aluminum foil
3004 aluminum foil element content
| AL3004 aluminum foil metal composition (%) | |||||||||
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Ti | Others | Al |
| 3004 | 0.3 | 0.7 | 0.25 | 1.5 | 0.8-1.3 | 0.25 | 0.1 | 0.2 | ≥90 |
Aluminum foil 3004 alloy strength
The strength of 3004 aluminum alloy foil is 10% higher than that of series 1 aluminum foil, and it has good formability, weldability and corrosion resistance. For processing, 3004 aluminum foil has good formability and high corrosion resistance, and can meet the environment required for processing.
Aluminum foil 3004 equivalent name
- AL 3.0526
- A93004
- ENAW-3004
3004 aluminum foil mechanical properties
| Alloy Temper | Tensile Strength | Yield Strength | Elongation(mm) | ||
| 3004-o | 115-175MPa | 16,700-25,400 psi | 70-140 MPa | 10,000-20,300 psi | 25% |
| 3004-H14 | 140-185 MPa | 20,300-26,800 psi | 25-165 MPa | 18,100-24,000 psi | 6-10% |
| 3004-H16 | 165-205 MPa | 23,900-29,700 psi | 150-190 MPa | 21,800-27,600 psi | 4-8% |
| 3004-H18 | 185-225 MPa | 26,800-32,600 psi | 175-210 MPa | 25,400-30,500 psi | 3-7% |
| 3004-H22 | 140-185 MPa | 20,300-26,800 psi | 125-165 MPa | 18,100-24,000 psi | 6-10% |
| 3004-H24 | 165-205 MPa | 23,900-29,700 psi | 150-190 MPa | 21,800-27,600 psi | 4-8% |
| 3004-H26 | 185-225 MPa | 26,800-32,600 psi | 175-210 MPa | 25,400-30,500 psi | 3-7% |
| 3004-H28 | 215-255 MPa | 31,200-37,000 psi | 205-240 MPa | 29,700-34,800 psi | 2-6% |
Applications of Huawei Aluminum 3004
3004 aluminum foil is widely used in food packaging, container foil, and aluminum foil lunch boxes.
●Aluminum foil containers:
Aluminum foil containers made of 3004 aluminum foil are stronger than 3003 aluminum foil. 3004 aluminum foil has both the price advantage of 8011 aluminum foil and the strength advantage of 3003 aluminum foil.
3004 aluminum foil containers have neat appearance and good thermal conductivity. It can be heated directly in the original packaging using oven, microwave, steamer and other kitchen utensils.
●Honeycomb aluminum foil:
The aluminum honeycomb core is a hexagonal aluminum honeycomb structure, which is widely used in decorative materials, household appliances, lighting industry, transportation industry, and furniture industry. The raw material of the aluminum honeycomb core is 3004 aluminum foil, H18/H19 status, high strength, not easy to deform after processing, the surface of the aluminum foil is degreased and clean, and the glue is not easy to fall off.
The strength is much higher than that of 1100 aluminum foil. The processed product is not easy to deform, the end face is flat, the edges are burr-free, and the layout after adhesive lamination is highly flat.
●Air conditioning foil:
Common air conditioning aluminum foils include 1100/3003/3004/8011 alloy, etc. The 3004 aluminum foil used as fin material for air conditioning heat exchangers is an aluminum-manganese alloy with good corrosion resistance, excellent formability, high strength and elongation, etc., and meets the mechanical performance requirements of air conditioning foils.
3004 aluminium foil density
At room temperature (25°C or 77°F), the density of 3004 aluminium foil is approximately 2.71g/cm³(2.7×10³kg/m³). This value is a typical density for aluminum alloys (including 3004) and may vary slightly depending on the specific manufacturing process and the exact composition of the foil.
Aluminum 3004 foil melting point
The melting point of aluminum alloy 3004 is approximately 658-660°C (1216-1220°F). This is the temperature at which the solid aluminum in the foil transforms into a liquid state.
Performance characteristics of 3004 aluminum foil
Aluminum alloy 3004 foil has a variety of performance characteristics to suit a variety of applications.
1.3004 foil has good formability and can be easily formed into different structures without cracking or breaking.
2. Corrosion resistance: 3004 alloy has good corrosion resistance and is suitable for use in environments with moisture and other corrosive factors.
3. Strength and durability: 3004 provides sufficient strength for the intended application.
4. High-quality printing: 3004 aluminum foil has a smooth and consistent surface, making it ideal for high-quality printing and branding, such as food packaging.
5. Heat resistance: It has good heat resistance, which makes it suitable for applications that involve heat exposure or need to act as a thermal barrier.
6. Light weight: 3004 aluminum foil is a lightweight material.
7. Ductility: 3004 aluminum foil is ductile and can be easily stretched and bent without breaking.
